If you have gone through the initial setup of the Raspberry Pi and setup a network connection you can get the IP address by using the ifconfig command on the Raspberry PI. You will have to know the IP address of your Raspberry Pi to connect to it. Its great, you can just drag a file from one window to the other to move files between systems. This is a great introduction to designing things for CAD/CAM and it is really easy to use.Īfter creating a design that I wanted to use I wirelessly connected to the Raspberry Pi using WinSCP to transfer design files to the Raspberry Pi.
#SHARK CNC USB CONTROLLER LED PRO#
I have used a few tools on my Windows 8.1 Pro laptop to design a few simple things (like tutorials in makercam here: ). The Raspberry Pi processes an "nc" file that contains a design that is described in GCode commands that can be understood by the Arduino. I have now built an Arduino based CNC Controller system that uses a Raspberry Pi as its host computer. It kept on changing until I finally got my project completed. I created a Visio drawing of what I intended to do: It didn't turn out that way and the drawing continued to evolve as I learned more. So I modified my solution and started working on using a Raspberry Pi as my host computer. The Arduino UNO just does not have enough memory or processing capacity to process a design file by itself. I decided that I would try to put together an Arduino based controller and try to use USB to communicate with it.Īfter studying that for a while I came to realize the Arduino was just not going to be able to do all that needed to be done on its own. So I started looking for another solution. I used an old Pentium based computer and ran LinuxCNC on it for a while but was still not happy with that. It used a traditional parallel port controller and of course no modern computers have those. I bought a CNC machine some time ago and I was never happy with it. Please read through the comments for more details. This is my first attempt at an instructable.
